Steel

Y Cable mounted RJ45 In & Out

7.2 Feet

74°

Dual Yoke

​

Electrical specifications

LED Type:

Color Temp WW:

CRI: (Warm White)

Lumens @ Full:

LED Qty:

Each LED Watts:

Power Input:

Total Max Power:

​Drive Method:

SMD 5050 R,G,B,WW

2475K

74

1107lm

140

.25

24V DC

32W

Constant Voltage (to be used with Deco Drivers)

​

Control Protocols:

Channel Modes:

​

​

Display:

DMX 512 (WHEN USING DECO DRIVER)

2 Modes of operation

Mode 1: 4 Channel mode

Mode 2: 7 Channel mode

Digital

Dimensions

Fixture Size:

​

Fixture Weight:

Packaged Size:

​

Packaged Weight:

22.75"X 14.5” X 25.98“

(57.7cm X 36.8 X 65.9)

13 lb (5.8 kg)

28" X 24" X 16"

(71.1cm X 60.9 X 40.6)

19 lb (8.6kg)
