Description
Designed to seamlessly control our Light Pipe and Deco Line, this all-in-one solution has 16 outputs that can be individually addressed with in your preferred channel mode.
To further enhance versatility, this powerful driver features removable racks ears, allowing for easy wall mounting rack mounting, or rear rack installation, accommodating various setup requirements.
Deco Line brings smart technology to any space — effortlessly. Featuring intuitive lighting controllers and low-voltage LED fixtures, this system is designed for easy integration in homes, hotels, and commercial environments.
Features
The device features sixteen RJ45 output ports, designed to efficiently transmit control signals to the Deco Line lighting fixtures ensuring seamless integration and reliable performance in professional lighting setups.
SIXTEEN RJ45 OUTPUTS
Benefit from the added advantage of Remote Device Managment (RDM) signal regeneration. The Tetra Driver 16 restores and stabilizes RDM signals, allowing you to maintain constant control and monitoring of you DMX lighting fixtures.
FIELD MOUNTABLE
rdm:
With its flexible field-mountable design, this unit is perfect for indoor installations, ensuring precise lighting control and enhancing the ambiance of your events.
The power of DMX, CABLE-FREE
Gallery
Video
Specifications
Mechanical specifications:
Housing:
Display:
IP Rating:
Fastening system:
DMX connection:
Power connection:
Output connection:
Control & programming
Protocol:
DMX 7 modes::
RDM:
Operating mode:
Aluminum
Digital
Rack mount, removable clamp mounts, Rear rail removable mounts.
5 Pin XLR in and out & RJ45 in and out
Seetronics SAC3MPA
(Seetronic SAC3FCA to nema 5-15 cable included)
16 X RJ45 outputs
DMX 512
7 Modes of operation:
16 Channel mode 16 x Dimmer
32 Channel mode 16 x WW, CW
48 Channel mode 16 x R, G, B
64 Channel mode 16 x R, G, B, W
112 Channel mode 7 ch Dimmer, R, G, B, W, Strobe, Macro
Yes, Addressing, Channel mode control
17 Pre Programs
Manual settings via display
Electrical specifications:
Output ports:
Power per port:
Drive method:
Total max power:
Power supply:
Output:
Working ambient temp:
Refresh:
Power input:
Dimensions:
Fixture Size:
Fixture Weight:
Packaged size:
Packaged weight:
16
96W
Constant voltage
960W
2 x Mean Well UHP
24V DC
24° F - 148° F
4,000 Hz
90-264V AC 50/60Hz
19" x 10.5" x 3.5"
(48.26 cm x 26.67 cm x 8.89cm)
12 lbs (5.4 kg)
21.3" x 13" x 5.5"
(54.10cm x 33.02cm x 13.97cm)
16.5 lbs (7.4 kg)
