Description
The MS1 is part of the M series. This compact unit is equipped with a bright 150 Watts LED. With versatile uses, this unit features two prims, a 3-segment animation effect, 6 bi-rotational gobos, mechanical focus, and 7 colors + aperture that allow you to create colorful effects.
Powerful stepper motors allow the unit to create fast and slow movements in as little as 1.8 seconds for a 540° pan and 0.9 seconds for a full 270° tilt.
The MS1 can be used in numerous applications, such as churches, theaters, mobile DJs, and nightclubs, adding attractive multicolor effects.
Features
The three-phase motors of the MS1 allow smooth movement, 1.8 seconds for full rotation and 0.9 seconds for full tilt.
Three-phase motors
Features 4 and 6-facet circular overlay prism, 3-segment animation effects, and 6 bi-rotational gobos to create unique aerial effects.
very bright
UNIQUE EFFECTS
It is equipped with 150 Watts LED power which can produce a bright powerful, and even projection.
Gallery
Video
Specifications
Mechanical specifications:
Housing:
Power connection:
Signal connection:
Pan:
Tilt:
Shutter:
Strobe:
Prism 1:
Prism 2:
Animation effect:
Gobo rotation:
Focus:
Color:
Tilt and rotation lock:
Fastening system:
ABS plastic
PowerCON-type input and output
5 and 3-pin input and output connectors
540° 8/16-bit, 3 motors per phase
270° 8/16-bit, 3 motors per phase
Electronic shuttter
20 flashes/second
6 overlapping circular faceted prisms
4 overlapping circular faceted prims
3-segment animation effects
6 non-removable bi-rotational gobos
Mechanical focus
7 colors (+aperture)
Yes
2 bi-directional quick-release clamps
Electrical specifications:
Light source:
Color temperature:
CRI (warm white):
Lumen output:
Power supply:
Power consumption:
Dimensions:
Fixture size:
Fixture weight:
Packaged size:
Packaged weight:
Control systems:
Control protocols:
DMX channels:
Control options:
Display:
1 x 150 W LED
11,026 K
81
5,968 lm
100-240 V, 50/60 Hz
236 Watts | 2.97 Amps
11.8" x 9" x 18.75"
24.5 lb (11.11 kg)
14.5" x 12" x 17.5" x 17.5"
26 lb (11.79 kg)
DMX512
2 modes of operation
Mode 1: 17 channel mode
Mode 2: 21 channel mode
Individual pixel control, RDM
LCD Display
