Description
Eight port Art-Net rack mountable DMX interface.
The MEGA Node 8 is a versatile ArtNet to DMX adapter designed to expand DMX networks. Each node converts Ethernet data into 8 universes of DMX signal. Pair one more nodes with Enlighten, Disco or Lumen8 products to add up to 24 additional universes and give yourself better control over your setup.
Features
BUILT IN
TERMINATOR
BUILT IN DMX
TERMINATOR
SWITCH
3 AND 5 PIN
XLR
3 AND 5 PIN
INPUTS AND
OUPUTS
ELECTRONIC
ISOLATION
USED BETWEEN
INPUTS AND
OUTPUTS
FRONT LED
INDICATORS
STATUS /
ACTIVITY LEDS
Gallery
Video
IP rating:
Housing:
Power connection:
Signal connection:
Fastening system:
IP22
Extruded aluminum
USB-C
USB-C
4 hole points / Din rail adapter
Specifications
Mechanical Specifications:
Input DMX connections:
Output DMX connectors:
Power connection:
Fastening system:
Electrical Specifications:
Electronic isolation between input & output
Electronic isolation between output and output
Terminator button for last unit
Power indicator
Signal indicator
Power consumption: 110V-60Hz
Front and rear 3-pin & 5-pin XLR connectors
4 output / 3-pin & 5-pin XLR connectors
IEC power connection to Edison
1U Rack mountable front and back & wall mountable.
-1 Amp.
6
Dimensions:
Fixture Size:
Fixture Weight:
Packaged Size:
Packaged Weight:
19" x 1.75 x 3"
5 lbs.
20" x 7.5" x 3"
6 lbs.
