Specifications
Mechanical specifications:
Housing:
Power connection:
Signal connection:
Lens angle:
Segments:
Fastening system:
Control systems:
Control protocols:
Channel modes:
Display:
Sheet Metal
Seetronics SAC3MPX Input (NEMA 5-15 to SAC3FX-67 cable included)
5-pin XLR in and out
5°
40 pixeles
Mounting yoke
DMX512
4 Modes of operation
Mode 1: 3 channel mode
Mode 2: 9 channel mode
Mode 3: 120 channel mode
Mode 4: 129 channel mode
LED
Electrical specifications:
Light source:
Power supply:
Power consumption:
Dimensions:
Fixture size:
Fixture weight:
Packaged size:
Packaged weight:
40 X 3W RGB LEDs
Electronic 100 - 240 V AC 50/60 Hz
65 Watts | .84 Amps @110V
37.7" x 2" x 6"
6 lb
40.5" x 4.9" x 5.7"
6.5 lb
