Description
MEGA-LITE has revamped the infamous scanner by creating the Stinger Scan-150, wich uses an LED light source. Designed to be more efficient and deliver a high output, this fixture features a 150 W single-color LED.
It is packed with the effects you need: eight colors + open, seven removable bi-directional and indexing rotation gobos, a 4-facet rotable indexing prism, mechanical focus, 180° pan, and 140° tilt. This ficture can deliver sharp mid-air beams with hight-speed movement and yet be an efficient scanner with great slow movements.
When placed against a wall or on the floor, the scanning power fits into areas where other moving head fixtures dont' make sense. The fast mirror pace is ideally suited for high-energy music and high-impact lighting, adding excitement to any event.
Features
Designed to be more powerful and deliver a high output, this fixture features a powerful 150W single color LED.
powerful
The movement can either be fast and energic scanning the room with is super fast mirror or deliver precise movement to be focused in a specific area.
packed with effects
extreme movement
The fixture is packed with 8 colors + open, 7 removable, bi-directional, indexing rotation gobos, and a 4-facet, rotable, indexing prism.
Gallery
Video
Specifications
Mechanical specifications:
Housing:
Power connection:
Signal connection:
Pan movement:
Tilt movement:
Colors:
Focus:
Rotating gobos:
Prism:
Lens angle:
Fastening system:
Control systems:
Control protocols:
RDM:
Channel modes:
Display:
Steel and plastic
Panel mounted powerCON-type in and out
Panel mounted 5-pin XLR connector in and out (3-pin optional)
180°
140°
8 colors+ open
Mechanical focus
7 removable, bi-directional, indexing
4-facet, rotable, indexing
15°
Mounting yoke and can stand on the flor
DMX 512
Yes
2 modes of operation:
Mode 1: 8 channel mode
Mode 2: 15 channel mode
LCD display
Electrical specifications:
Light source:
Color temperature:
CRI (warm white):
Lumen output:
Power supply:
Power consumption:
Dimensions:
Fixture size:
Fixture weight:
Packaged size:
Packaged weight:
150 W single color
16403 K
77
5733 lm
Electronic auto-switching
100 - 240 V, 50/60 Hz
272 Watts | 2.3 Amps
15" x 6.5" x 18.5"
(26.67 x 16.51 x 46.99 cm)
16.5 lb (7.5 kg)
23.25" x 12" x 20"
(59 x 30.48 x 50.8 cm)
20 lb (9 kg)
