Specifications
Mechanical specifications
Housing:
Power Connection Input:
Output:
Cable:
Signal Connection:
LED Angle:
Segments:
Fuse:
Fastening System:
Control System:
Control Protocols:
Channel Modes:
Display:
Sheet Metal
Seetronics SAC3MPX
Seetronics SAC3FX
Seetronics SAC3FX to Nema 5/15
5 Pin XLR In and Out n
140° (outer ring)
8 outer segments, 8 inner segments
5x20mm F10AL250V
2 Quick Release Clamp Mounts,
Hanging yoke
DMX 512
5 Modes of operation
Mode 1: 2 Channel mode
Mode 2: 3 Channel mode
Mode 3: 17 Channel mode
Mode 4: 52 Channel mode
Mode 5: 55 Channel mode
Digital
Electrical specifications
LED Quantity:
LED Watts:
Power Input:
Scan Rate:
Power Supply:
Power Consumption:
Power Link:
Dimensions
Fixture Size:
Fixture Weight:
Case Size:
Case Weight:
384 RGB Outer Ring, 288 Inner Ring, 80
Warm White + Amber Center, 180 Warm
White Reflective
0.8 Watts each
110-240VAC 50/60Hz
7000 Hz
100-240 A/C
445 Watts / 5.43Amps @110V
4 units
39.37” X 27.92” X 34”
(99.99cm X 70.91cm X 86.36cm)
51lb (23.13kg)
42" X 25 3/8" X 48
(106.68cm X 63.5 3/8cm X 121.92cm)
160lb (72.57kg)
