Description
The Baby Color Q70 is equipped with seven 10W LEDs, the output of the Baby Color Q70 contends with the output of larger fixtures. The fixture has a 20° beam angle and comes with a diffuser that increases the beam angle to 25°.
This unit is controllable via DMX 512 and has a double mounting yoke so it can be set upon the floor or hang from a structure. It has a digital display designed for ease of use.
Features
This compact, powerful fixture is just five pounds, making it ideal for touring or permanent installations.
COMPACT
Seven 10W RGBW LEDs allow for color mixing with red, green, blue, and white.
UNIQUE EFFECTS
RGBW
Using DMX 512, create dimmer, strobe, and macro effects.
Gallery
Specifications
Mechanical specifications:
Power Connection:
Signal Connection:
Lens Angle:
Diffusion Beam Angle:
Fastening System:
Control systems:
Control protocols:
Channel modes:
Display:
Powercon type in and out
3 pin XLR connectors in and out
20°
25°
Dual mounting yoke
DMX 512, Audio Trigger,
Master and follow units
3 Modes of Operation
Mode 1: 3 Channel mode
Mode 2: 4 Channel mode
Mode 3: 7 Channel mode
LED
Electrical specifications:
Light source:
Color temperature:
CRI (warm white):
Lumen Output:
Power supply:
Power consumption:
Dimensions:
Fixture size:
Fixture weight:
Packaged size:
Packaged weight:
7 X 10W RGB LEDS
8125 K
74
2319 lm
110V-240 50/60 Hz
48 Watts | .74 Amps
8.25” x 4.25” x 7.25
(20.95 cm x 10.79 cm x 18.41 cm)
5 Ib (2.26 kg)
10.25” x 9.5” x 6.25”
(26.03 cm x 24.13 cm x 15.87 cm)
6Ib (2.72 kg)
